Description
|
Model No. |
SCP400/32S |
|
Type |
Single Mast |
|
Rated load |
4000Kg |
|
Platform Max Length |
32m |
|
Lifting speed |
6m/min |
|
Platform Basic width※ |
1.5m |
|
Platform Max width |
2.5m |
|
Max Free Standing Height |
3m |
|
Max Erecting Height |
150m |
|
Mast Section Size (L x W x H)※ |
0.7*0.7*1.508m |
|
Mast Distance |
7.3-13.3m |
|
Interval Distance of Tie-in |
3-9m |
|
Weight of platform(without mast) |
1000Kg |
|
I type platform section length |
1.22m |
|
Motor power |
2×2×3Kw |
|
Power Voltage |
380/440V |
|
Power Frequency |
50Hz / 60Hz |
※Please contact us for other size
