Description
|
Model |
SDC3023 |
|
Version |
Brand new & unused |
|
Working Type |
Stationary on roof |
|
Working Radius |
30m |
|
Working Angle: |
360 degree |
|
Max Load |
10t |
|
Tip Load |
2.3t |
|
Hoisting Mechanism |
45LVF |
|
Luffing Mechanism |
24DVF |
|
Slewing Mechanism |
9RVF |
|
Electric Cable |
30m |
|
Wire Rope Drum |
500m |
|
Control |
Portable Joystick |
|
Power Supply |
380V/50Hz; 440V/60Hz |
